| الاسم التجاري: | Sinuo |
| رقم الطراز: | SNQC1006B-6500A |
| الـ MOQ: | 1 |
| شروط الدفع: | تي/تي |
| القدرة على التوريد: | 10 مجموعات في الشهر |
| Parameter | Specification |
|---|---|
| Output Workstation | 1 DC output station |
| Maximum Output Voltage | DC less than 15V |
| Constant Adjustable Test Current Output | DC 200-6500A |
| Current Display Accuracy | ±(0.25% of reading + 0.25% of range), resolution 1A |
| Voltage Display Accuracy | ±(0.25% of reading + 0.25% of range), resolution 0.01V |
| Test Current Stability | ±(1% of set value + 0.5A), response time approximately 1s |
| Control Contact Power Supply | Current range AC (0-2) A |
| Operating Modes | Continuous mode, On/Off mode, Automatic temperature control mode |
| Temperature Measurement Range | 0-260°C, Accuracy: ±0.3% of reading + 1°C; Resolution: 0.1°C |
| Temperature Measurement Points | 16 channels (including 1 point for measuring ambient temperature) |
| Thermocouple Types Supported | J, K, T, E, S, N, B, R types |
| Thermocouple Used for Measurement | USA Ω Company K-type 30AWG fine wire thermocouples, length 2 meters, 20 pieces total |
